Luo | Catenary Optics | E-Book | www.sack.de
E-Book

E-Book, Englisch, 419 Seiten

Reihe: Chemistry and Materials Science

Luo Catenary Optics


1. Auflage 2019
ISBN: 978-981-13-4818-1
Verlag: Springer Nature Singapore
Format: PDF
Kopierschutz: 1 - PDF Watermark

E-Book, Englisch, 419 Seiten

Reihe: Chemistry and Materials Science

ISBN: 978-981-13-4818-1
Verlag: Springer Nature Singapore
Format: PDF
Kopierschutz: 1 - PDF Watermark



This book offers the first comprehensive introduction to the optical properties of the catenary function, and includes more than 200 figures. Related topics addressed here include the photonic spin Hall effect in inhomogeneous anisotropic materials, coupling of evanescent waves in complex structures, etc. After familiarizing readers with these new physical phenomena, the book highlights their applications in plasmonic nanolithography, flat optical elements, perfect electromagnetic absorbers and polarization converters. The book will appeal to a wide range of readers: while researchers will find new inspirations for historical studies combining mechanics, mathematics, and optics, students will gain a wealth of multidisciplinary knowledge required in many related areas. In fact, the catenary function was deemed to be a “true mathematical and mechanical form” in architecture by Robert Hooke in the 1670s. The discovery of the mathematical form of catenaries is attributed to Gottfried Leibniz, Christiaan Huygens and Johann Bernoulli in 1691. As the founders of wave optics, however, Hooke and Huygens did not recognize the importance of catenaries in optics. It is only in recent decades that the link between catenaries and optics has been established.


Luo Catenary Optics jetzt bestellen!

Autoren/Hrsg.


Weitere Infos & Material


1;Foreword;5
2;Preface;7
3;Contents;9
4;1 Introduction;14
4.1;1.1 Concepts and Brief History;14
4.2;1.2 Catenary Function in Optics and Electromagnetics;27
4.2.1;1.2.1 The Mirage;27
4.2.2;1.2.2 Solar Concentrator;29
4.2.3;1.2.3 Optical and Quantum Tunneling;32
4.2.4;1.2.4 Geodesic Antenna;34
4.2.5;1.2.5 Wireless Energy Transfer;37
4.2.6;1.2.6 Accelerated Charges in Uniform Electric Fields;37
4.2.7;1.2.7 Coupling Between Atoms and Meta-atoms;38
4.3;1.3 Misconceptions and Controversies;43
4.3.1;1.3.1 FAST;43
4.3.2;1.3.2 Brachistochrone;43
4.3.3;1.3.3 Glacial Valley;45
4.3.4;1.3.4 Freely Supported Beam and Cantilever Beam;48
4.4;1.4 Overview of the Book;48
4.5;References;50
5;2 Spin-Controlled Beam Shaping with Catenary Subwavelength Structures;54
5.1;2.1 Introduction to Spin, Linear and Angular Momentum of Light;54
5.2;2.2 Spin-Momentum Locking in Free Space and Guided Waves;55
5.2.1;2.2.1 Guided Wave: Surface Plasmon Polaritons;56
5.2.2;2.2.2 Free Space: Circularly Polarized Beam at Oblique Incidence;57
5.3;2.3 Spin Hall Effect Generated by a Single Catenary Aperture;59
5.4;2.4 Integration Design of the Catenary Array;65
5.5;2.5 Wide-Angle Lenses and Airy Beam Generation;74
5.5.1;2.5.1 Wide-Angle Flat Lens;74
5.5.2;2.5.2 Airy Beam Generation Based on Cubic Phase;79
5.6;2.6 Optical Vortex and High-Order Bessel Beam Generation;82
5.6.1;2.6.1 Achromatic Optical Vortex;82
5.6.2;2.6.2 Bessel Beam Carrying Optical Vortex;84
5.7;2.7 Catenary Devices with Maximized Efficiency;90
5.7.1;2.7.1 Metal–Dielectric Composites;91
5.7.2;2.7.2 All-Metallic Catenary Meta-Mirror;93
5.7.3;2.7.3 All-Dielectric Catenary Devices;96
5.8;2.8 Coherent Control of the Diffraction Efficiency of Catenary Metasurface;98
5.9;References;102
6;3 Catenary Structures for Spin-Dependent Coupling of Waveguide Modes;106
6.1;3.1 Catenary Apertures for Unidirectional Excitation of SPP;106
6.1.1;3.1.1 Discrete Spin-Controlled Unidirectional Coupler;107
6.1.2;3.1.2 Catenary Unidirectional Coupler;112
6.2;3.2 Spin-Controlled Router for SOI Waveguide;117
6.3;3.3 Catenary-Shaped Waveguides;122
6.4;References;128
7;4 Catenary Plasmons for Sub-diffraction-Limited Imaging and Nanolithography;130
7.1;4.1 Catenary Optical Fields in Plasmonic Waveguides;130
7.1.1;4.1.1 Transfer Matrix Analysis of Metal–Dielectric Multilayer;130
7.1.2;4.1.2 Catenary Optical Fields as Plasmonic Eigenmodes;132
7.1.3;4.1.3 Catenary Plasmons in Superlens;136
7.2;4.2 Sub-diffraction-Limited Nanolithography with Planar Lens;141
7.2.1;4.2.1 Reflective Superlens;141
7.2.2;4.2.2 Plasmonic Imaging of Dense Lines;145
7.2.3;4.2.3 Plasmonic Imaging of Complex Patterns;148
7.3;4.3 Demagnifying Imaging Based on Curved Hyperlens;151
7.3.1;4.3.1 Numerical Simulation;151
7.3.2;4.3.2 Experimental Demonstration;154
7.4;4.4 Interference Lithography of Periodic Patterns;158
7.4.1;4.4.1 Normal Incidence;158
7.4.2;4.4.2 Oblique Incidence;160
7.5;4.5 Interference Lithography of Aperiodic Patterns;164
7.5.1;4.5.1 Polarization-Dependent Catenary Optical Fields;164
7.5.2;4.5.2 Interference of Circular Polarizations;164
7.6;4.6 Plasmonic Direct Writing Based on Catenary Plasmons;168
7.6.1;4.6.1 Metallic Tip;168
7.6.2;4.6.2 Bowtie-Shaped Nanoapertures;171
7.6.3;4.6.3 Virtual Scanning Tip;175
7.7;References;182
8;5 Catenary Plasmons for Flat Lensing, Beam Deflecting, and Shaping;185
8.1;5.1 Young’s Double Slits Interference with Unequal Widths;185
8.1.1;5.1.1 Far-Field EYI;186
8.1.2;5.1.2 Near-Field EYI;189
8.2;5.2 Wavefront Shaping via Plasmonic Slits;191
8.2.1;5.2.1 Plasmonic Deflector and Generalized Snell’s Law;191
8.2.2;5.2.2 Flat Lens Based on Plasmonic Nanoslits;195
8.2.3;5.2.3 Tunable Plasmonic Nanoslits Lens;198
8.3;5.3 Plasmonic Hole Lens;201
8.3.1;5.3.1 Rectangular Holes;201
8.3.2;5.3.2 Circular Holes;207
8.4;5.4 Achromatic Optical Lens Based on Nanoslits Array;211
8.5;5.5 Super-Oscillatory Metalens;215
8.6;5.6 Structural Colors and Color Holography;222
8.6.1;5.6.1 Structural Colors Based on Linear Dispersion of Catenary Plasmons;222
8.6.2;5.6.2 Structural Colors Based on Polarization Conversion;224
8.6.3;5.6.3 Color Holography;230
8.7;References;236
9;6 Beam Shaping via Microscopic Meta-surface-wave;241
9.1;6.1 Microscopic Meta-surface-wave;241
9.1.1;6.1.1 Catenary Theory of the Microscopic M-Waves;242
9.1.2;6.1.2 Application of M-Wave in Amplitude and Phase Modulation;245
9.2;6.2 All-Metallic Surface Structure for Virtual Shaping;247
9.3;6.3 Broadband Virtual Shaping via Layered Metasurfaces;257
9.4;6.4 Achromatic Skin Cloak;262
9.5;6.5 Wide-Angle Beam Steering;267
9.6;6.6 Switchable Beam Manipulation via Phase-Change Materials;275
9.7;References;281
10;7 Catenary Optical Fields and Dispersion for Perfect Absorption of Light;285
10.1;7.1 Critical Coupling Associated with Catenary Optical Fields;285
10.2;7.2 Broadband Absorption Based on Coupled Resonators;291
10.2.1;7.2.1 Structure and Generalized Impedance Theory;292
10.2.2;7.2.2 Fano Resonance Induced by Coupled Modes;297
10.2.3;7.2.3 Design of Broadband Absorbers;301
10.3;7.3 Dispersion Engineering for Broadband Metasurface Absorber;301
10.4;7.4 Catenary Dispersion Model for Broadband Absorption;309
10.4.1;7.4.1 Microwave Absorber;310
10.4.2;7.4.2 Terahertz Absorber;314
10.5;7.5 Coherent Perfect Absorption in Metallic Thin Films;318
10.6;7.6 Catenary Plasmons for Solar Cell Enhancement;325
10.6.1;7.6.1 Localized Field Enhancement in Plasmonic Grating;325
10.6.2;7.6.2 Catenary Model for the Localized Field Enhancement;327
10.7;References;331
11;8 Catenary Optical Fields for Thermal Emission Engineering;334
11.1;8.1 Introduction;334
11.2;8.2 Beyond Planck’s Thermal Radiation Law;338
11.2.1;8.2.1 Near-Field Thermal Radiation with Flat Surfaces;340
11.2.2;8.2.2 Near-Field Thermal Radiation with Structured Surfaces;341
11.2.3;8.2.3 Far-Field Super-Planckian Thermal Radiation;344
11.3;8.3 Coherent Thermal Radiation;346
11.3.1;8.3.1 Coherent Thermal Radiation Based on Surface Waves;346
11.3.2;8.3.2 Coherent Thermal Radiation in Graphene;348
11.4;8.4 Perfect Thermal Radiation;353
11.4.1;8.4.1 Metamaterials;353
11.4.2;8.4.2 Metal–Dielectric Multilayers;357
11.5;8.5 Reduction of Thermal Radiation in Pseudo-Brewster Angle;359
11.6;References;363
12;9 From Catenary Optics to Engineering Optics 2.0;366
12.1;9.1 Basic Laws of Traditional Engineering Optics;366
12.2;9.2 Young’s Interferences of Photons, Electrons and Coupled Plasmons;368
12.2.1;9.2.1 Shrunk Interference Patterns in EYI;369
12.2.2;9.2.2 Shifted Interference Patterns in EYI;370
12.2.3;9.2.3 Modulated Transmission in EYI;371
12.2.4;9.2.4 Extraordinary Vertical Fabry–Perot Interference;372
12.3;9.3 Generalized Optical Theories and Their Applications;373
12.3.1;9.3.1 Generalized Diffraction Theory Based on Catenary Optical Fields;373
12.3.2;9.3.2 Generalized Laws of Reflection and Refraction;377
12.3.3;9.3.3 Generalized Theory for Absorption and Radiation;379
12.4;9.4 Conclusions and Outlooks;382
12.5;References;383
13;Appendix A: Catenary Function for a Freely Hanging Chain;388
14;Appendix B: Matlab Codes for GDSII File Generation;392
15;Appendix C: Matlab Codes for Vectorial Diffraction;412
16;Appendix D: Quasi-Stationary Catenary Optical Fields;414
17;Appendix E: Matlab Codes for the Transfer Matrix Method;419
18;Appendix F: Gallery of Pictures for Catenary;422
19;References;428
