Wang Investigation on SiGe Selective Epitaxy for Source and Drain Engineering in 22 nm CMOS Technology Node and Beyond

1. Auflage 2019
ISBN: 978-981-15-0046-6
Verlag: Springer Singapore
Format: PDF
Kopierschutz: 1 - PDF Watermark

E-Book, Englisch, 115 Seiten

Reihe: Physics and Astronomy

This thesis presents the SiGe source and drain (S/D) technology in the context of advanced CMOS, and addresses both device processing and epitaxy modelling.
As the CMOS technology roadmap calls for continuously downscaling traditional transistor structures, controlling the parasitic effects of transistors, e.g. short channel effect, parasitic resistances and capacitances is becoming increasingly difficult. The emergence of these problems sparked a technological revolution, where a transition from planar to three-dimensional (3D) transistor design occurred in the 22nm technology node.
The selective epitaxial growth (SEG) method has been used to deposit SiGe as stressor material in S/D regions to induce uniaxial strain in the channel region. The thesis investigates issues of process integration in IC production and concentrates on the key parameters of high-quality SiGe selective epitaxial growth, with a special focus on its patterndependency behavior and on key integration issues in both 2D and 3D transistor structures, the goal being to improve future applications of SiGe SEG in advanced CMOS.

Zielgruppe

Research

Autoren/Hrsg.

Wang, Guilei

Inhaltsverzeichnis

Introduction.- Strain technology of Si-based materials.- SiGe Epitaxial Growth and material characterization.- SiGe Source and Drain Integration and transistor performance investigation.- Pattern Dependency behavior of SiGe Selective Epitaxy.- Summary and final words.

Über Autor(innen)

Dr. Guilei WANG  received his Ph.D. degree from the University of Chinese Academy of Sciences. His research Interests mainly include Semiconductor Material Growth and Device Fabrication.
