Parhi Pipelined Lattice and Wave Digital Recursive Filters

1996
ISBN: 978-1-4613-1307-6
Verlag: Springer US
Format: PDF
Kopierschutz: 1 - PDF Watermark

E-Book, Englisch, Band 344, 224 Seiten, eBook

Reihe: The Springer International Series in Engineering and Computer Science

uses look-ahead transformation and constrained filter design approaches. It is also shown that pipelining often reduces the roundoff noise in a digital filter. The pipelined recursive lattice and wave digital filters presented are well suited where increasing speed and reducing area or power or roundoff noise are important. Examples are wireless and cellular codec applications, where low power consumption is important, and radar and video applications, where higher speed is important.
The book presents pipelining of direct-form recursive digital filters and demonstrates the usefulness of these topologies in high-speed and low-power applications. It then discusses fundamentals of scaling in the design of lattice and wave digital filters. Approaches to designing four different types of lattice digital filters are discussed, including basic, one-multiplier, normalized, and scaled normalized structures. The roundoff noise in these lattice filters is also studied. The book then presents approaches to the design of pipelined lattice digital filters for the same four types of structures, followed by pipelining of orthogonal double-rotation digital filters, which eliminate limit cycle problems. A discussion of pipelining of lattice wave digital filters follows, showing how linear phase, narrow-band, sharp-transition recursive filters can be implemented using this structure. This example is motivated by a difficult filter design problem in a wireless codec application. Finally, pipelining of ladder wave digital filters is discussed.
serves as an excellent reference and may be used as a text for advanced courses on the subject.

Zielgruppe

Research

Autoren/Hrsg.

Parhi, Keshab K.

Inhaltsverzeichnis

Preface. 1. Introduction. 2. Pipeline interleaving in digital filters. 3. Pipelining direct form recursive digital filters. 4. Roundoff noise in pipelined recursive digital filters. 5. Schur algorithm. 6. Digital lattice filter structures. 7. Pipelining of lattice IIR digital filters. 8. Pipelining of orthogonal double-rotation digital lattice filters. 9. Pipelined lattice WDF design for wideband digital filters. 10. Synthesis and pipelining of ladder WDFs in digital domain. A: Derivation of (3.3),(3.5) and (3.23). B: Derivation of case (A) in section 10.4 C: Derivation of case (E) in Section 10.4. References.
