Rimmer Biomedical Hydrogels

Biochemistry, Manufacture and Medical Applications
1. Auflage 2011
ISBN: 978-0-85709-138-3
Verlag: Elsevier Science & Techn.
Format: EPUB
Kopierschutz: 6 - ePub Watermark

E-Book, Englisch, 288 Seiten

Reihe: Woodhead Publishing Series in Biomaterials

Hydrogels are very important for biomedical applications because they can be chemically manipulated to alter and control the hydrogel's interaction with cells and tissues. Their flexibility and high water content is similar to that of natural tissue, making them extremely suitable for biomaterials applications. Biomedical hydrogels explores the diverse range and use of hydrogels, focusing on processing methods and novel applications in the field of implants and prostheses. Part one of this book concentrates on the processing of hydrogels, covering hydrogel swelling behaviour, superabsorbent cellulose-based hydrogels and regulation of novel hydrogel products, as well as chapters focusing on the structure and properties of hydrogels and different fabrication technologies. Part two covers existing and novel applications of hydrogels, including chapters on spinal disc and cartilage replacement implants, hydrogels for ophthalmic prostheses and hydrogels for wound healing applications. The role of hydrogels in imaging implants in situ is also discussed. With its distinguished editor and international team of contributors, Biomedical hydrogels is an excellent reference for biomedical research scientists and engineers in industry and academia, as well as others involved in research in this area, such as research clinicians. - Examines the diverse range and use of hydrogels, focusing on processing methods and novel applications - Comprehensive book explores the structure and properties of hydrogels and different fabrication technologies - Covers important areas such as processing of hydrogels, covering hydrogel swelling behaviour, superabsorbent cellulose-based hydrogels and regulation of novel hydrogel products

Autoren/Hrsg.

Rimmer, Steve

Leseproben

1

Hydrogel swelling behavior and its biomedical applications

H. Holback, Y. Yeo and K. Park,     Purdue University, USA

Abstract:

The ability of hydrogels to respond to relatively small changes in stimuli with relatively large changes in volume allows a wide variety of applications. This chapter addresses hydrogels with regard to the chemical identity of hydrophilic polymers and copolymers, polymer synthesis, the degree of crosslinking and hydrogel porosity, and bulk geometry of hydrogels in the form of matrix, membrane and erodible systems. The relationships between these features and hydrogel swelling behavior upon stimulation are also described. Finally, various exploitations of hydrogel swelling behavior in developing highly sensitive, real-time biosensors are discussed.

Key words

hydrogels

superporous hydrogels (SPHs)

swelling

environment-sensitive

1.1 Basics of hydrogels

Hydrogels gained increased attention from the scientific community in the latter half of the 20th century (Brannon-Peppas and Peppas, 1991). The ability of hydrogels to respond to relatively small changes in external stimuli with relatively large changes in bulk volume enables direct detection of a variety of stimuli (Gemeinhart 2000; Lee and Park, 1996; Peppas , 2000; Roy and Gupta, 2003). The chemical makeup, synthesis, crosslinking, and geometry of hydrogels are briefly described.

1.1.1 Chemical identity of hydrophilic polymers and copolymers

Hydrogels are composed of hydrophilic polymer chains. These chains may consist of repeating monomers (homopolymers) or chemically different monomers (copolymers) (Peppas 2000). As depicted in Fig. 1.1, monomers can be arranged in such a way to make random copolymers, alternating copolymers, block copolymers, or graft copolymers. Additionally, the polymer chains may form more intricate three-dimensional structures, such as five-pointed star polymers, or dendrimers (Jeong 2002). The selection of chemical makeup of a polymer is critical to controlling swelling behavior, since these constituents are responsible for interactions with water and subsequent volume change (Peppas 2000). For example, hydrogels with hydrophobic internal cores would be well suited for delivery of poorly water-soluble drugs (Jeong 2002).

1.1 Chemical diversity of hydrogel polymer chains. (a) homopolymer, (b) random copolymer, (c) alternating copolymer, (d) block copolymer, and (e) graft copolymers. Rectangular and circular units represent chemically different monomers.

1.1.2 Polymer synthesis

Polymer synthesis is tailored according to the need to develop chemically diverse hydrogels for specific applications (Brannon-Peppas and Peppas, 1991; Peppas 2000). Depending on the application, the synthesized polymers may require biocompatibility, mechanical strength, or analyte specificity in addition to sensitivity to stimuli (Brannon-Peppas and Peppas, 1991; Lee and Park, 1996; Peppas 2000; Kim and Park, 2001b; Kim and Park, 2004). Table 1.1 lists monomers used in synthesizing hydrogels for pharmaceutical applications. Polymers are synthesized by various mechanisms, such as radical polymerization, condensation polymerization, graft-copolymerization, photopolymerization, and ring-opening polymerization (Lee and Park, 1996; Kim and Park, 2001b; Lee 2003; Xiao, 2007; Pearton 2008; Xue 2004; Plunkett 2003; Gu 2002). Care must be taken to purify the synthesized hydrogels for pharmaceutical and biomedical applications by removing the residual monomer, initiator, crosslinking agent and other contaminants (Markowitz 1997; Risbud 2000; Peppas 2000).

Table 1.1

Examples of monomers used in pharmaceutical applications

Monomer

Acrylic acid (AA)

Ethylene glycol (EG)

Hydroxyethyl methacrylate (HEMA)

-isopropyl acrylamide (NIPAAm)

-vinyl-2-pyrrolidone (NVP)

Poly(ethylene glycol acrylate) (PEGA)

Source: Peppas (2000)

1.1.3 Degree of crosslinking and porosity

Hydrogels are crosslinked either physically or chemically to form networks (Peppas 2000; Roy and Gupta, 2003). Physical crosslinking occurs via noncovalent interactions, whereas chemical crosslinking utilizes covalent interactions (Lin 2005). The degree of crosslinking plays a significant role in the integrity and swelling properties of hydrogels, influencing hydrogel structure and swelling capacity (Flory and Rehner, 1943; Brannon-Peppas and Peppas, 1991). The greater the extent of crosslinking, the less flexible a hydrogel is to shrink, swell or change phase in response to stimuli (Peppas 2000). Hydrogel brittleness has been observed at high degrees of crosslinking (Peppas 2000). Physical crosslinks are often used in hydrogel formation due to their ability to reform crosslinks upon removal or presentation of the stimulus (Roy and Gupta, 2003; Lee and Park, 1996; Lee 2004).

Hydrogels have a range of porosities that influence the diffusion coefficients involved in mass transfer during swelling (Peppas 2000; Bezemer 2000). Pore size is dependent on the average molecular weight of polymer chain segments between adjacent crosslinks and acts as a selective barrier with regard to the permeability of substances (Peppas 2000). Specifically, swelling can be decreased by decreasing the average molecular weight of the polymer chain segments between crosslinks (Brannon-Peppas and Peppas, 1991). Pore size can be further controlled by various techniques, such as freeze drying, porosigen method, or gas formation method (Gemeinhart 2000). Therefore, the pores can range from a few nanometers to several micrometers (Kim and Park, 2004).

1.1.4 Bulk geometry of hydrogels

Hydrogels can be molded into various geometries, ranging from microspheres to films, and this makes their application highly versatile (Roy and Gupta, 2003). Hydrogel matrixes can be used as implantable scaffolds, due to their structural properties and ability to absorb or release bioactive substances (Roy and Gupta, 2003; Pearton 2008; Markowitz 1997; Risbud 2000; Lee 2003; Mauck 2002; Gombotz and Wee, 1998). Table 1.2 lists hydrogels that have been studied for controlling the release of bioactive substances. Due to the relative thickness of a hydrogel matrix (as compared to membranes), the rate of diffusion for drug molecules through the matrix may be impeded (Zhang and Wu, 2002). Conversely, hydrogel membranes are relatively thin and offer increased response rate (swelling or shrinking) to stimuli due to the shorter distance required for diffusion (Zhang and Wu, 2002). Such hydrogels, capable of preventing degradation of labile substances, act as their reservoirs until stimulated (Pearton 2008; Markowitz 1997; Risbud 2000; Mauck 2002; Bezemer 2000). Similarly, erodible hydrogels are of interest in the pharmaceutical field as their ability to exhibit zero-order release kinetics has been well established (Peppas 2000; Lee, 1984).

Table 1.2

Examples of the use of hydrogels in biomedical applications

Note:

*seeded in hydrogel

1.2 Swelling of hydrogels: water diffusion into hydrogels

The ability to display a measurable change in volume in response to external stimuli is a fundamental property of hydrogels (Lee and Park, 1996). Some hydrogels exhibit this volume change by swelling (see Fig. 1.2), while others undergo transitions between sol and gel phases (Brannon-Peppas and Peppas, 1991; Gemeinhart 2000; Lee and Park, 1996; Jeong 2002). When hydrogels swell, the glassy phase turns into the rubbery phase (Lee, 1984). The degree of crosslinking influences the area permitted for diffusion across the hydrogel network and, subsequently, the capacity for hydrogels to take up water (Peppas 2000). The water capacity is depicted from the equilibrium swelling ratio shown in Equation 1.1, as the ratio of the mass of a fully swollen hydrogel (in equilibrium with aqueous medium) to the mass of a dehydrated hydrogel (Brannon-Peppas and Peppas,...
